BEHAVIORAL SIMULATION OF INDUCTION MOTOR TEMPERATURE DISTRIBUTION |
|---|---|
| รหัสดีโอไอ | |
| Creator | Alexander A. Pugachev, A.Yu. Drakin, A.N. Shkolin |
| Title | BEHAVIORAL SIMULATION OF INDUCTION MOTOR TEMPERATURE DISTRIBUTION |
| Contributor | - |
| Publisher | TuEngr Group |
| Publication Year | 2563 |
| Journal Title | International Transaction Journal of Engineering, Management, & Applied Sciences & Technologies |
| Journal Vol. | 11 |
| Journal No. | 3 |
| Page no. | 11A03F: 1-18. |
| Keyword | Asynchronous motor, AC electric motor, Behavioral simulation, Equivalent thermal circuit, Power losses, Finite element model, Differential equations, Control system, State and rotor windings, Cooling system, Overheating. |
| URL Website | http://TuEngr.com/Vol11_3.html |
| Website title | ITJEMAST V11(2) 2020 @ TuEngr.com |
| ISSN | 2228-9860 |
| Abstract | The paper justifies the need to monitor and control the thermal state of the induction motor as a whole and its windings, as the most heat-loaded elements. A review of modern methods of measuring and determining the temperature of windings (including rotating) is carried out. It showed trends in the use of non-contact methods for determining temperature using mathematical models based on the finite element method and relevant thermal equivalent circuits. To determine the temperature distribution, an equivalent thermal model of an induction motor, consisting of 53 nodes, 31 of which are heat generating was developed. To determine the losses, a T-shaped equivalent circuit for replacing motor windings was used, taking into account losses in steel, non-linearity of the magnetization curve and the effect of current displacement in the rotor winding. The simulation results in steady and transient modes are presented. |
