Development of a game boy based radiation survey meter |
|---|---|
| รหัสดีโอไอ | |
| Creator | 1. Piyathep Chobthumkit 2. Decho Thong-Aram 3. Suvit Punnachaiya |
| Title | Development of a game boy based radiation survey meter |
| Publisher | Faculty of Engineering, Khon Kaen Univeristy |
| Publication Year | 2555 |
| Journal Title | KKU Engineering Journal |
| Journal Vol. | 39 |
| Journal No. | 1 |
| Page no. | 77-83 |
| Keyword | Survey meter, Game boy, Microcontroller, Exposure rate,Geiger Muller counter |
| ISSN | 0125-8573 |
| Abstract | This research aimed to develop a game boy based radiation survey meter for radiation dose rate measurement. The measuring range of exposure rate in the range of 0-100 mR/hr and count rate in the range of 0-5.5 x104 CPM were designed to display on the game boy monitor with 3 automatically ranges changing. The system composed of 4 main parts: e.g., the thin window Geiger Muller detector, high voltage power supply, signal pulse shaper and interfacing part for communication between radiation counter and game boy in form of a plug-in game cartridge under the cooperation of microcontroller PIC16F877A and PSD813F2. By applying a game boy as a base operation of the developed radiation survey meter, it was found that the graphic display utility gave high flexible support in analog and digital display designing, both alpha-numerical measuring unit and analog meter. Moreover the function and joy stick keys were useful for assigning the control functions of measuring system, resulted in affordable and ease of use. The power consumption was 296 mW and with 700 mA-hr Li-ion battery, the continuous operation last 8 hours. For the exposure rate calibration using a 662 keV of cesium-137 standard source, it was found that at exposure rate range, e.g. (100 mR) x0.01, x0.1, and x1 gave measuring errors of less than ?2.2%. In addition, the developed system could be used for measurement a counting rate of alpha and beta radiations. |
