Prediction of Head Stack Assembly Gram Load Using Finite Element Analysis |
|---|---|
| รหัสดีโอไอ | |
| Creator | 1. Khemakorn Chaloemsri 2. Sujin Bureerat |
| Title | Prediction of Head Stack Assembly Gram Load Using Finite Element Analysis |
| Publisher | Faculty of Engineering, Khon Kaen Univeristy |
| Publication Year | 2553 |
| Journal Title | KKU Engineering Journal |
| Journal Vol. | 37 |
| Journal No. | 1 |
| Page no. | 55-63 |
| Keyword | Finite element analysis, Swaging process, Hard disk drive, Contact analysis,Head stack Assembly. |
| ISSN | 0125-8273 |
| Abstract | This paper presents a finite element model for simulating a swaging process of a hard disk drive (HDD) head stack assembly (HSA). The swaging process is a material processing technique using swage balls to connect a suspension system to an E-block which becomes the so-called head stack assembly. The finite element (FE) model is three-dimensional using an explicit dynamics simulation with solid Lagrangian elements. In this paper, the base plate and arm tip deformations due to ball swaging and the impact of the head stack gram load value are evaluated. The simulation results are compared to those obtained from experimentation. It was found that the results from FE analysis are well-corresponding to the experiment results. |
