การศึกษาความต้านทานการสึกหรอและโครงสร้างจุลภาคของแนวเชื่อมพอกผิวทองเหลืองที่ผ่านกระบวนการแล่นประสาน |
|---|---|
| รหัสดีโอไอ | |
| Creator | วิโรจน์ ฉัตรเกษ |
| Title | การศึกษาความต้านทานการสึกหรอและโครงสร้างจุลภาคของแนวเชื่อมพอกผิวทองเหลืองที่ผ่านกระบวนการแล่นประสาน |
| Contributor | สำเนียง ไข่มุกข์, วราภรณ์ อักโขวงศ์, อนุรักษ์ ตัณฑวรา |
| Publisher | ์Nakhon Phanom University |
| Publication Year | 2564 |
| Journal Title | Journal of Engineering Technology Access |
| Journal Vol. | 1 |
| Journal No. | 2 |
| Page no. | 1-10 |
| Keyword | Wear Resistance, Microstructure, Brass, Brazing |
| URL Website | https://ph02.tci-thaijo.org/index.php/JETA/about |
| Website title | https://ph02.tci-thaijo.org/index.php/JETA/index |
| Abstract | The objective of this research is to study the wear resistant and microstructure of welding zone brass for brazing processed. To be using to fix the brass nut lock of the water gate valve set of Plumbing systems, Irrigation, and component parts of brass. The experiment was conducted by using Brass material has outside diameter 30 mm. inner diameter 19 mm. to all drilling, and Brazing processed by Brass filler diameter 2.4 and 3.2 mm. and Touch Number 1, 3 and 5, gas flow rate 65, 160 and 350 lt/h., respectively. For Microstructure analysis, Optical Emission Spectroscopy, Hardness and Wear testing. To compare the test specimen that have been brazing to the original brass, and brass nut. The experimental result shows that the optimal process size brass filler were the diameter 2.4 mm. and Touch Number 5 has the hardness 160 HV because gas flow rate is suitable to Brazing process. Microstructure of welding has homogeneity and defect is porosities on the surface weld is less than other experimental variables. But has microstructure similar and consisted of alpha (67 %) + beta phase (20%), place is placed alternately and has black dots spread into round beads within the structure. Because of the specimen have been alloys copper between zinc, and tin (59.91% Cu - 37.85% Zn - 2.02% Pb), respectively. Which be effect to hardness decrease according to the element chemical and has the fretting wear. Because of the friction force to be particles of brass removed and weight loss rate increase follow to time. |
