การแทรกค่าเชิงพื้นที่ของความลึกดินโดยใช้วิธีการและจำนวนจุดตัวอย่างที่แตกต่างกันบริเวณลุ่มน้ำห้วยคอกม้า จังหวัดเชียงใหม่ |
|---|---|
| รหัสดีโอไอ | |
| Creator | ปรารถนา ชุมทอง |
| Title | การแทรกค่าเชิงพื้นที่ของความลึกดินโดยใช้วิธีการและจำนวนจุดตัวอย่างที่แตกต่างกันบริเวณลุ่มน้ำห้วยคอกม้า จังหวัดเชียงใหม่ |
| Contributor | ชัชชัย ตันตสิรินทร์ |
| Publisher | King Mongkut’s University of Technology Thonburi |
| Publication Year | 2565 |
| Journal Title | KMUTT Research and Development Journal |
| Journal Vol. | 45 |
| Journal No. | 3 |
| Page no. | 295-308 |
| Keyword | Spatial Interpolation, Soil Depth, Kog Ma Watershed |
| URL Website | https://journal.kmutt.ac.th/ |
| Website title | เว็บไซต์วารสารวิจัยและพัฒนา มจธ. |
| ISSN | 2697-5521 |
| Abstract | Distributed soil depth information is essential data for applying hydrological and landslide models. Data from direct measurement can nevertheless be obtained merely at sampling locations. Spatial interpolation therefore becomes an important technique for generating distributed soil depth information from measured point data. This study systematically measured 103 points to a depth at topsoil and bedrock within a 0.65-km2 forested watershed using a knocking cone penetrometer. Different spatial interpolation methods, including Inverse Distance Weighted (IDW), Kriging, Cokriging (COK), Local Polynomial (LP), and Global Polynomial (GP), and varying number of sampling points, i.e., 86, 46, and 22 points, were employed to generate distributed soil depth information. Comparison of spatial distribution and spatial interpolation error (SIE) obtained using different methods and number of sampling points was carried out based on the correlation coefficient (r), and root mean square error (RMSE). Analysis of variance was conducted to verify the differences of mean square error (MSE). The results revealed that the depths of topsoil ranged between 0.37-2.59 m, with an average ("x" ̅) and standard deviation (SD) of 0.94 and 0.39 m, respectively, while the depths to bedrock were 1.13-14.60 m, with "x" ̅ of 5.25 and SD of 3.34 m. These results indicated a higher variance of the depths to bedrock than those to the topsoil. Comparison of different spatial interpolation methods showed that the distribution of soil depths of both layers as obatianed from the IDW method was highly correlated (r > 0.9) to the COK method. SIE of the depths to topsoil as obtained using the IDW method was statistically the lowest (RMSE is 0.1561) only when compared with that obtained using the COK(slp) method. SIE of the depths to bedrock were similar (RMSE ranges from 1.8187 to 1.9170 m) and not statistically different. A comparison using the different number of sampling points of both soil layers illustrated that the correlation among spatial distributions wa not high. The decreasing number of sampling points of topsoil from 86 to 22 points increased SIE only when the IDW and Kriging methods were employed. Using 86 points of depths to bedrock statistically gave the lowest SIE only when the Kriging, COK (up), and COK (slp+up) methods were employed. |
